Automatic plane labeling machine (two label head) AS-P04
● PRODUCT INTRODUCTION
Technology parameters：According to customer request, detailed parameters can be customized.
|
1 |
Labeling accuracy | ±1mm (without products, and label error) |
|
2 |
Labeling speed | 40～100pcs / min（related to the size of label and products） |
|
3 |
Applicable product size | Length: 40mm -300mm; width: 40-200mm-mm; height: 0.2mm-80mm |
|
4 |
Applicable label size | Length: 6mm-150mm; width (bottom paper width): 15mm-120mm |
|
5 |
Size of this machine | About 1600mm × 850mm × 1400mm (L × W × H) |
|
6 |
Applicable power supply | 220V/50HZ |
|
7 |
Weight of this machine | About 180Kg |
Details of standard configurations（ The following is standard configuration, customer can chose what they really need）Some customized machine will increase the amount of accessory, according to completed machine to confirm.
| The main component configurations | The main electrical configurations | ||||
|
Name |
Amount |
Main material |
Electric name |
Amount |
Type specification |
|
Labeling head |
1 set |
Aluminum, stainless steel, Acrylic |
label-tested electric eye |
1 set |
SICK |
|
Adjustment stand |
1 set |
Aluminum, brass, stainless steel |
PLC |
1 set |
Panasonic |
|
Transfer component |
1 set |
stainless steel |
touch screen |
1 set |
Samkoon 7.0 Inch |
|
Bottom paper receiver
|
1 set |
stainless steel |
Traction motor |
1 set |
STONKER |
|
Adjustment framework |
1 set |
Aluminum, stainless steel |
Traction motor drive |
1 set |
STONKER |
|
Labeling framework |
1 set |
Aluminum, stainless steel, rubber bar
|
Labeling motor |
1 set |
OUBANG 120W |
|
Electric framework |
1 set |
Aluminum, stainless steel |
Object-tested electric eye |
1 set |
SUNX |
|
Guider |
1 set |
stainless steel |
Convey motor |
1 set |
OUBANG 180W |
|
Traction component |
1 set |
Aluminum, plastic packets shaft |
Conveyor motor speed controller |
1 set |
OUBANG |
|
Label putting tray |
1 set |
Aluminum, Acrylic |
|
|
|
